Lanco Type Threading Die Head

Lanco Type Threading Die Head
Lanco Type Threading Die Head
Product Code : 18
Product Description

We are one of the preeminent manufacturers, suppliers and exporters of high quality Lanco Type Threading Die Head. Made using fine-grade alloy steel, our die head is offered in different size, specification and cutting capacities. Post production, our team of quality controllers checks this product on various quality parameters to ensure end product meets with international quality standards. Our offered Lanco Type Threading Die Head is highly demanded for sturdy construction, corrosion resistance, hassle-free operations, high performance and longer service life.

Lanco Type Die Head Capacity

  • 1/4" to 1"
  • 3/8" to 1.1/2"
  • 1/2" to 2.1/2"
  • 1" to 4"

Lanco Type Die Head Capacity

  • 2.1/2" to 6"
  • 4" to 8"

Other Details:

A good grade Lanco Type Threading Die-Head will have a system that is so advanced that little human intervention will be required. This will not only ascertain that the work done is completed with perfection, but will also reduce human effort. The way these Lanco type threading die head are fabricated, the quality inspection team, ensures that there are no breakdowns, during operation.

We are reckoned among the best Lanco threading die head manufacturers in India. Lanco Type Threading die head manufactured by us is passed through stringent heat treatment in our advanced imported treatment plant. This threading die head is available in assortment of types with us such as Lanco type pipe threading die head, Lanco type bar threading die head, Lanco type bolt threading die head and Lanco type rebar threading die head, Lanco type rod threading die head, Lanco type pvc pipe threading die head and Lanco type bar threading die head. These threading die head are efficient enough to give high performance in loner use. We facilitate our client’s by providing easy accessibility of these threading die head at most reasonable prices.

IMC HEAT Treated die head are of revolving type for application to hand operated, semi accurate to hand operated, semi automatic & automatic threading machines of rugged construction the Die heads provide accurate and trouble free operation over long production runs.

Constructed of specially selected alloys steel, the IMC Die Head are recommended for threading upto and including class 3 tolerances and are well known for their ability to cut coarse pitch threads in a single pass. They have wide range converge, permit rapid set up, gives trouble free operations.

Technical Specifications

Die Head Size

Holder Set/Sets (Provided)

Chaser Section

1/4" to 1" Capacity Die Head

1/4" to 1"

3" x 1.3/64 (Set of 4 Pcs)

3/8" to 1. 1/2" Capacity Die Head

3/8" to 1. 1/2"

4" x 1.3/64 (Set of 4 Pcs)

1/2" to 2.1/2" Capacity Die Head

1/2" to 1. 1/2"
1.5/8 to 2.1/2"

4" x 1.1/4" (Set of 4 Pcs)

1" to 4" Capacity Die Head

1" to 2"
2.1/2" to 4"

4" x 1.1/4" (Set of 4 Pcs)
5" x 2.1/4" (Set of 4 Pcs)

2.1/2" to 6" Capacity Die Head

2.1/2" to 3"
3.1/2" to 4"
4.1/2" to 6"

5" x 2.1/4" (Set of 6 Pcs)

4" to 8" Capacity Die Head

4" to 5.1/2"
5.1/2" to 8"

5" x 2.1/4" (Set of 6 Pcs)
